GPS Positioning
Track Playback · Real-time Tracking · Geo-fencing
NFC (Card)
Card Unlock · Card Start · Battery Swap Access
BLE (Bluetooth)
Auto Unlock · Remote Control · OTA Update
Mobile App
Vehicle Management · Battery Monitoring · Remote Control
4G Network
Data Upload · Remote Lock/Unlock · Real-time Monitoring
This product is a TFT intelligent instrument system for electric vehicles, which is gradually optimized based on ordinary instruments. Use ITE chip, large memory, sufficient capacity. Support multimedia Settings, theme diversification, WiFi, screen projection, upgrade in one of the intelligent instrument system. Matching APP use, so that customers handy, to achieve intelligent riding, fashion sense.Through CAN, 485 or first-line communication with the electric vehicle controller, central control, BMS and other components, to obtain the body battery power, mileage, tire pressure status and vehicle condition and fault data. Users can view vehicle battery data, remaining mileage, cycling mileage, speed, network signal, GPS signal and other information through the instrument interface. Enter the menu page through the knob button, support to set different riding modes, multimedia sound, set tire pressure value reference range, set personalized theme,support multi-language switching, support mirror screen projection, support WiFi upgrade.
Bottom Menu Bar Icon Switcher From left to right: “Battery Status, Audio Settings, Dashboard, Tire Pressure Status, System Menu” Highlighted indicates the current page
Displays “7-day battery consumption, charging count, battery temperature”, retains status bar and bottom menu bar (for more efficient switching and information display)
Displays “Front tire pressure, Left rear tire pressure, Right rear tire pressure”, with tire pressure value setting entry in the top-left corner Retains status bar and bottom menu bar (for more efficient switching and information display)
Displays “Vehicle Self-Check, Network Signal, Language Settings, OTA” setting entry Secondary page to be designed after entry Retains status bar and bottom menu bar (for more efficient switching and information display)
Displays “Startup sound, Shutdown sound, Alarm sound, Turn signal” and their status Allows quick switching (3 options available) Retains status bar and bottom menu bar (for more efficient switching and information display)
ZT02 is a beidou GPS positioning terminal specially designed for electric vehicle lithium battery positioning. It is portable and dual-purpose, easy to install and waterproof. The product can be used for location tracking, vehicle anti-theft, with vehicle positioning, stroke playback, vibration alarm,remote power failure, BMS data transmission, Bluetooth transmission, disassembly alarm,power/voltage/temperature display, touch keys, buzzer alarm, etc. , the utility model has the advantages of simple operation, practical and beautiful assembly of the lithium battery box.
Operating voltage：9V-100V
Standby current：2.5mA@48V
Standby sleep：3mA
Offline dormancy：1.5mA
Network：Network (Full Netcom)
Positioning mode：BD +GPS positioning + base station positioning
Operating temperature：－20°C ～75°C
Working humidity：5%～ 95％
shell：Flame retardant, waterproof
